Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance

Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance

Lieu d'origine Chine
Nom de marque TBC LED
Certification FCC, CE, ROHS
Numéro de modèle P8.33
Détails de produit
taper:
Périmètre extérieur du stade de football LED
Pas de pixels:
P8.33 mm
Taille de l'armoire:
Pour les véhicules à moteur électrique
service:
Service avant et arrière
Poids:
45KG
Type de LED:
SMD3727 à haute luminosité
Angle de vision:
H160°/V160°
Consommation d'énergie maximale (W/㎡):
600-800
Garantie:
3 ans
Conditions de paiement et d'expédition
Quantité de commande min
10 m²
Prix
Négociable
Détails d'emballage
Cas de vol
Délai de livraison
25 jours
Conditions de paiement
T/T
Capacité d'approvisionnement
1000 m² par mois
Description de produit
Outdoor P8.33 Perimeter LED Display IP65 Front Rear Maintenance Stadium Screen
Outdoor P8.33mm LED Perimeter Folding Aluminum Bracket 7000nits High Brightness 3840Hz Refresh Rate
Product Specifications
ParameterSpecification
ModelP8.33mm
LEDs1R1G1B
LED TypeSMD2727
Pixel Pitch8.33mm
Unit SizeW1600*H900mm
Unit Resolution192*108 dots
Resolution14,400 dots/㎡
Unit DirectionVertical Horizontal
Brightness7000nit
Weight45KG/Panel
Max Consumption600-800W/㎡
Average Consumption100-200W/㎡
Viewing AngleH160°/V160°
Protection LevelIP65
Thickness98mm
Heat DissipationConvective heat dissipation
Power SupplyPower supply with PFC
InstallationFast install
ServiceFront & Back
Control ModeSteady state
Color Temperature3200-9300K
Refresh Rate3840Hz
Working Temperature-40℃ to 70℃
Storage Temperature-55℃ to 120℃
Life Time≥100,000 hours
Input VoltageAC90-264V
Grey Grade16bit
Warranty3 years
Key Features
  • Polymer soft mask for better contrast and player protection
  • High-quality aluminum cabinet - only 45kg per panel
  • Ultra-thin design - just 98mm thickness
  • IP65 protection rating on both front and rear sides
  • 160° super wide viewing angle
  • 7000cd/㎡ brightness with 5000:1 contrast ratio
  • 16-bit gray scale processing technology
  • Adjustable folding brackets with multiple angle options
  • Full front and rear maintenance access
  • Seamless splicing with perfect flatness
Product Images
Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 0 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 1 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 2 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 3 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 4 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 5 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 6 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 7 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 8 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 9 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 10
Our Services
  • 10 Years professional LED display manufacturing experience
  • Short delivery time: 5-15 working days
  • Competitive wholesale pricing
  • OEM and ODM services available
  • Customizable products upon request
Frequently Asked Questions
How does the service work?
We have experienced engineers with 15+ years in the industry who provide technical support via video conference, TeamViewer, or on-site guidance.
What installation options do we have?
Wall mounting with metal structures.
Do you have any MOQ limit for LED screen orders?
Low minimum order quantity - modules or complete screen orders are all welcome.
What's the shipping method?
Air freight, sea, and train transport available depending on region.
What's the payment method?
Telegraphic transfer - 50% before production and 50% balance before shipment.
How do you control the production quality?
Quality management from incoming materials, pre-inspected components, and 72+ hours aging tests for modules and complete screens.
How does warranty work?
1-3 years warranty with free repair or exchange of defective parts including one-way shipping.
